If you are looking for a heatsink simple and effective to remove heat from your CPU, Cooler Master just announced a solution to this problem. The manufacturer, which has multiple cooling solutions in its catalogue, it has presented the new Hyper 212 3DHP. A simple but efficient heatsink, which now includes the 3DHP technology that improves heat transfer to the tubes to improve dissipation on your CPU.

The new Cooler Master Hyper 212 3DHP improves heat transfer

3D Heat Pipe or 3DHP (3D Heat Pipe) technology has been added to this basic Cooler Master model that also comes in black or with RGB lighting options. It has a system of 2 heat pipeswhich have been improved with this technology to evaporate, condense and direct heat from the base to the heatsink fins. Furthermore, this new design is capable to distribute more effectively heat through all the fins of the heatsink, which will improve efficiency when removing it with the fan.

Geeknetic Cooler Master adds 3DHP technology to its Hyper 212 heatsink, available in black or with RGB for 29 euros 2

3DHP technology to improve heat transfer from the CPU to the Heat Pipes

The 3DHP come into direct contact with the CPU at the base of the cooler, which better collects the heat from the IHS and improves the transfer to the tubes, and these to the fins.

Geeknetic Cooler Master adds 3DHP technology to its Hyper 212 heatsink, available in black or with RGB for 29 euros 3

Available in black or with RGB fan

As we mentioned previously, it is available in a black versionand a version coming with fan with RGB lighting. It has a height of 158 mm that fits into most cases on the market. Your fan offers a static pressure of 2.69 H2O and a flow of 63.1 CFM running at 2,050 RPM, with a minimum noise level of only 27 dB(A).

Geeknetic Cooler Master adds 3DHP technology to its Hyper 212 heatsink, available in black or with RGB for 29 euros 4

Its noise level is minimal at only 27 dB(A)

Both models will be available in Europe shortly, with a recommended price of 29.99 eurosalthough maybe you can find it in some bargain in our price comparator.

These are the complete specifications of both models.

Specification

Hyper 212 3DHP Black

Hyper 212 3DHP Black ARGB

Exterior color

Black

Black

Cooling type

Air (Air Cooler)

Air (Air Cooler)

Lightning

No (without LED)

Yeah, Addressable ARGB Gen 2

Intel® Compatibility

LGA 1851 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156

LGA 1851 / 1700 / 1200 / 1151 / 1150 / 1155 / 1156

AMD® Compatibility

AM5/AM4

AM5/AM4

Dimensions (L × W × H)

133 × 86 × 158mm

133 × 86 × 158mm

Heatsink material

2 3DHP heat pipes + aluminum fins

2 3DHP heat pipes + aluminum fins

Number of fans

1

1

Fan dimensions

120 × 120 × 25mm

120 × 120 × 25mm

Fan type

Without LED

ARGB Gen 2 (illuminated)

fan speed

0–2050 RPM ±10%

0–2050 RPM ±10%

air flow

107.2 m³/h (63.1 CFM)

107.2 m³/h (63.1 CFM)

static pressure

2.69 mmH₂O (max.)

2.69 mmH₂O (max.)

noise level

22.6 dBA (max.)

22.6 dBA (max.)

Bearing type

Loop Dynamic Bearing (LDB)

Loop Dynamic Bearing (LDB)

fan connector

4 pin (PWM)

4 pin (PWM) + ARGB

Rated voltage

12VDC

12VDC

Rated current

0.12A

0.12A

Maximum safe current

0.35A

0.35A

Power consumption

1.44W

1.44W

Heatpipes

2 (3DHP)

2 (3DHP)

Fan MTTF

>200,000 hours

>200,000 hours

Warranty

5 years

5 years
