Memories are reaching speeds that seemed unthinkable a few years ago, exceeding 10,000 MT/s. But these figures seem increasingly common, since they are even cited as compatible in motherboards latest from the main manufacturers. MSI has launched a new motherboard compatible with this figure, in addition to adding other features, it is the small board MSI MPG X870I EDGE TI EVO WIFI in a color edition white which many users like so much.

The MSI MPG X870I EDGE TI EVO WIFI board supports 10,000 MT/s memory

MSI has launched this small motherboard, aimed at playersand with X870 chipset for AMD with socket Current and future AM5. The notable thing about this Mini ITX size board is that it supports DDR5 memory with a speed of up to 10,000 MT/s when installed alongside compatible CPUs. For the rest, despite its small size, it comes with a 8+2+1 phase system to deliver sufficient and stable power, with 110A, built on a 12-layer server grade PCB.

Geeknetic MSI MPG X870I EDGE TI EVO WIFI board is small but tough, PCIe 5.0 for SSD and GPU, Wi-Fi 7 and USB-4 2

8+2+1 phase system with 110A and server grade PCB

As a high-end motherboard, it comes with support for PCIe 5.0 in the main graphics slot, as well as the M.2 SSD storage slot It is offered as a secondary board just above the PCIe 5.0 x16. A second small plate Along with the RAM memories, it also offers front USB-C connectivity with 27W of PD and 2 USB-A 5 Gbps, along with two additional SATA slots and a second connector for M.2 PCIe 4.0 SSD drives. Also comes with a third slot for PCIe 4.0 SSD disks, which this time has been located on the back.

Geeknetic MSI MPG X870I EDGE TI EVO WIFI board is small but tough, PCIe 5.0 for SSD and GPU, Wi-Fi 7 and USB-4 3

It has 3 slots for SSD drives, 1 PCIe 5.0 and 2 PCIe 4.0

For connectivity, it has been added Wi-Fi 7 wireless internet connectionalong with a 5 Gbps RJ45 connector. In addition to this it includes multiple USB ports 40, 20 and 10 Gbps USB-A and C along with HDMI output.

Geeknetic MSI MPG X870I EDGE TI EVO WIFI board is small but tough, PCIe 5.0 for SSD and GPU, Wi-Fi 7 and USB-4 4

Wi-Fi 7 and USB 4 at 40 Gbps

For now It is not known what recommended price it has. this model, as well as its availability.

These are your technical specifications.

Chipset and CPU

  • Chipset: AMD X870
  • Socket: AM5
  • Supported processors:
    • AMD Ryzen™ 9000 / 8000 / 7000 Series (Desktop)

Memory

  • Slots: 3 × DDR5
  • Maximum capacity: 128GB
  • Supported frequencies:
    • DDR5 10000 – 5600 MHz (OC)
    • DDR5 5600 – 4800 MHz (JEDEC)
  • Maximum frequency with Ryzen™ 9000:
    • 1DPC 1R → up to 8400+ MT/s
    • 1DPC 2R → up to 8000+ MT/s
  • Modes and compatibility:
    • Dual Channel
    • AMD EXPO™
    • JEDEC and AMD support BY
    • Non-ECC memory, unbuffered
    • CUDIMM (Clock Driver bypass mode only)
    • Latch slots on one side only

Frequency and module compatibility depends on the installed processor. Consult the official list of supported memories at msi.com/support.

Integrated graphics

  • 1 × HDMI™ 2.1 (TMDS) — up to 4K @ 60 Hz*
  • 2 × DisplayPort type C
    Only available on processors with integrated GPU.

Expansion slots

  • 1 × PCIe x16 (from CPU)
    • PCIe 5.0 x16 → Ryzen™ 9000 / 7000
    • PCIe 4.0 x8 → Ryzen™ 8700 / 8600 / 8400
    • PCIe 4.0 x4 → Ryzen™ 8500 / 8300
  • 1 × FP Card slot (for MSI 5-in-1 XPANDER card)

Audio

  • Chip: Realtek® ALC4080
  • Channels: 7.1 High Performance USB
  • Quality: up to 32-bit/384 kHz (front panel)
  • S/PDIF output: Yeah

Storage

  • 3 × M.2
    • M.2_1 (from CPU): PCIe 5.0 x4 (Ryzen 9000/7000) / PCIe 4.0 x4 (Ryzen 8000)
    • M.2_2 (from chipset): PCIe 4.0 x4, 2260/2280, single-sided SSD
    • M.2_3 (XPANDER Card, from chipset): PCIe 4.0 x4, 2260/2280, single-sided SSD
  • 2 × SATA 6Gb/s
  • RAID:
    • SATA: RAID 0/1
    • NVMe: RAID 0 / 1 / 5 (Ryzen 9000 only)

USB connectivity

  • Frontal:
    • 2 × USB 2.0
    • 2 × USB 5Gbps Type-A
    • 1 × USB 20Gbps Type-C
  • Rear:
    • 5 × USB 10Gbps Type-A
    • 1 × USB 10Gbps Type-C
    • 2 × USB 40Gbps Type-C

Grid

  • LAN: Realtek® 8126 5GbE

Internal connectors

  • 1 × ATX 24 pin (ATX_PWR)
  • 1 × CPU_PWR
  • 1 × CPU Fan
  • 1 × Combo Fan (Pump/SYS Fan)
  • 1 × System Fan
  • 1 × EZ Conn (JAF_2)
  • 2 × Front Panel (JFP)
  • 1 × Chassis Intrusion (JCI)
  • 1 × Front Audio (JAUD)
  • 1 × ARGB V2 (JARGB_V2)
  • 2 × USB 2.0 headers
  • 2 × USB 5 Gbps Type-A headers
  • 1 × USB 20Gbps Type-C header

Wireless connectivity

  • Wi-Fi 7 (802.11 a/b/g/n/ac/ax/be)
    • 2.4/5/6 GHz (up to 320 MHz bandwidth)
    • Speed ​​up to 5.8 Gbps
    • MIMO TX/RX
    • MLO, 4K QAM
  • Bluetooth® 5.4 (depending on chip update and Windows 11 plan)
  • Module pre-installed in M.2 Key-E slot

Other features

  • 4 × EZ Debug diagnostic LEDs
